Marinas and tourist harbours
  • Former Regatta Club pontoon
200 m. in length with a depth of 4.60 m.
Mooring for sports and leisure boats.
  • C001-Scale Alfonso XII Royal Dock
Dock with 141 m. for mooring and a depth of 6.10 m.
Mooring for tourist boats.
  •  Cartagena Royal Regatta Club.
1,609 m. mooring line.
Capacity for 400 boats,
Sailing club, dry dock and refuelling service.
  • Cartagena Yacht Port - Cartagena Marina
From 12 m. boats to mega yachts
Berthing alongside and with finger
A full professional maintenance service
Private, closed marina with 24 hour security.
Free parking in the historic centre of the city



C002 Cruise Ship Terminal

700 m. mooring line.
11.25 m depth
Passenger Terminal
3,000 m2 esplanade
Parking area for buses and taxis.
Access control and tourist information point.

Fishing Facilities

Fishing harbour with a 575 m. mooring line and 3.60 m. depth.
Mooring dock that is 196 m. long and has a depth of 7.60 m.
Travelift with 200 ton lifting capacity and 7,199 m2 boat storage area
Ice factory (20 t/day).
Fish market of 1,425 m2, with facilities for fish preparation and packaging and cold stores with a capacity of 5,500 m3.
4,500 m2 of facilities to repair and dry nets.


SHIPYARDS
  • Navantia Group
Dry dock 216m. in length and 30 m. beam
Floating dock 119.88 m. in length and 30 m. exterior beam.
Shipyard of 176 m. in slipway length and 19.1 metres wide, with 3 slipways.
Multi-purpose repair dock 130x25 m. with 8,740 t lifting capacity and dry dock  with maximum 130m. length.
Dry dock
C006 Dry dock
Travelift with 200T lifting capacity and 7,199 m2 for boat storage
  • Ministry of Defence

Military Arsenal: dry dock with 3 slipways


  • Container Terminal C007 / C008
Dock with a mooring length of 385 m.
11.25 m depth
Total surface area: 127,174 m2 with 109,495 m2 of open air storage areas.
Quality Certification ISO 9001:2008 for Container Traffic.
Three container cranes: of 35, 40 and 57 t. which can handle 25/27 containers / hour.
64 tm Mobile crane handling 350t/h
Ro/Ro docking for this type of traffic
Railway terminal in the port
Border inspection post for third countries and for all types of goods.
200 power points for refrigerated containers.
Service centre for offices, official services and users.


Ro-Ro facilities for road traffic
C009 / C010

79 m. mooring line with a depth of 11.25 m.
Ro-Ro ramp for the loading and unloading road traffic roll-on / roll-off for containers and general cargo.


General Cargo Terminal
C010 / C011

Multi-purpose dock that is 405 m. long for mooring and a depth of 11.25 m.
Total surface area: 132,341 m2 with 97,874 m2 of open storage areas and 14,174 m2 covered storage areas.
Open shed with a surface area of 6,000 m2.
6 gantry cranes; three 6t cranes, a 12t crane  and two 16t cranes.
Ro/Ro docking for this type of traffic
Border inspection post for third countries and for all types of goods.
Quality Certification ISO 9001:2008 for general cargo traffic
Railway terminal in the port
Weighing bridge for 60t trucks

Fruit and Vegetable Terminal
C010 / C011

Dock with 405 m. of mooring and a depth of 11.25 m.
Cold stores with a capacity for 10,000 pallets.
Cold stores of 24,000, 10,500 and 7,500 m2
385 power points for refrigerated containers.
Availability and priority mooring for perishable cargo
Terminal included in the 360 Quality Code Association (Global System for Quality on arrival to prevent the cargo being contaminated)

Livestock terminal
C010 / C011

Mobile platform for safe, smooth and efficient animal-to-ship loading.
Transit area, control and separation of the animals.
Border inspection post
Possibility of loading forage for animal feed.
24 hour service, 365 days a year.
